  • 6DOF Vibration Sensors
  • 6DOF Vibration Sensors - 2
  • Variable Capacitance Technology
  • 6 Degrees of Freedom Measurements
  • Hermetically Sealed
  • DC Response
  • International Traffic in Arms Regulation (ITAR) Free
1 - 4 of 4 | Results Per Page | View | Unit of Measure
1
Request Information Compare Items

Item #

Item Name

Accelerometer Input Range (±)

Nominal Scale Factor

Accelerometer Resonant Frequency

Gyro Input Range (±)

N/A 6DOF 49.1 Meter Per Second Square (m/s²) Accelerometer Input Vibration Sensor N/A 5 g49.1 m/s² N/A 470 mV/g47.9 mV/m/s² N/A 3 kHz N/A 50 º/sec
N/A 6DOF 98.1 Meter Per Second Square (m/s²) Accelerometer Input Vibration Sensor N/A 10 g98.1 m/s² N/A 235 mV/g24.0 mV/m/s² N/A >2.8 kHz N/A 150 º/sec
N/A 6DOF 294 Meter Per Second Square (m/s²) Accelerometer Input Vibration Sensor N/A 30 g294 m/s² N/A 78.33 mV/g8.0 mV/m/s² N/A >5 kHz N/A 250 º/sec
N/A 6DOF 19.6 Meter Per Second Square (m/s²) Accelerometer Input Vibration Sensor N/A 2 g19.6 m/s² N/A 1175 mV/g119.8 mV/m/s² N/A 1.2 kHz N/A 50 º/sec
