Housing Material |
N/A Titanium |
Maximum Weight |
N/A 0.49 oz14 g |
Mounting Stud Mount |
N/A Screw: 10-32 UNF-2A |
Connector Type |
N/A 4-pin, 1/4-28 |
Note for Connector Type |
N/A Glass to metal seal connector. Mates with Dytran cable model 6811AXX (XX=length inn feet) |
Housing Isolation |
N/A Case Isolated |
Sensing Element Material |
N/A Ceramic |
Sensing Element Mode |
N/A Shear |
Maximum Peak Vibration (±) |
N/A 240 g2354 m/s² |
Operating Temperature Range |
N/A -60 to +235 ºF-51 to +113 ºC |
Environmental Seal |
N/A Hermetic |
Maximum Peak Shock (±) |
N/A 1000 g9810 m/s² |
Magnetic Sensitivity at 100 Gauss |
N/A 0.00007 g0.0007 m/s² |
Base Strain Sensitivity |
N/A 0.05 g’s/µs0.4905 m/s²/µε |
Resonant Frequency |
N/A >30 kHz |
Full Scale (F.S.) Linearity (±) |
N/A 1 % |
Note for Full Scale (F.S.) Linearity (±) |
N/A Measured using zero-based straight line method, % of F.S.or any lesser range. |
Maximum Transverse Sensitivity |
N/A 6 % |
Peak Acceleration Range (±) |
N/A 200 g1962 m/s² |
Root-Mean-Square (RMS) Noise Floor |
N/A 0.03 g0.0028 m/s² |
Root-Mean-Square (RMS) Spectral Noise at 1 Hertz (Hz) Frequency |
N/A 1962 µg200 µm/s² |
Root-Mean-Square (RMS) Spectral Noise at 10 Hertz (Hz) Frequency |
N/A 560 µm/s²5493.6 g rms/√ Hz |
Root-Mean-Square (RMS) Spectral Noise at 100 Hertz (Hz) Frequency |
N/A 360 µm/s²3531.6 g rms/√ Hz |
Root-Mean-Square (RMS) Spectral Noise at 1000 Hertz (Hz) Frequency |
N/A 200 µm/s²1962 g rms/√ Hz |
Root-Mean-Square (RMS) Spectral Noise at 10000 Hertz (Hz) Frequency |
N/A 80 µm/s²784.8 g rms/√ Hz |
Sensitivity ±5% |
N/A 25 mV/g2.5 mV/m/s² |
Note for Sensitivity ±5% |
N/A Measured at 100Hz, 1Grms per ISA RP 37.2 |
Frequency Range ±5% |
N/A 0.6 to 5000 |
Discharge Time Constant |
N/A 0.7 to 1.7 sec |
Typical Output Impedance |
N/A 100 O |
Minimum Electrical Isolation |
N/A 10 GO |
Direct Current (DC) Compliance Voltage Range |
N/A +18 to +30 V |
Power Supply Current Range |
N/A 2 to 20 mA |
Note for Power Supply Current Range |
N/A Do not apply power to this device without current limiting, 20mA Max. To do so will destroy the integral IC amplifier. |
Typical Direct current (DC) Output Bias Voltage |
N/A +11 to +13 V |
