Brands |
N/A Dytran |
Height |
N/A 0.188 in4.8 mm |
Frequency Response |
N/A Up to 10,000 Hz |
Type |
N/A Charge Mode |
Length |
N/A 0.267 in6.8 mm |
Width |
N/A 0.138 in3.5 mm |
Connector Type |
N/A Integral Cable |
Note for Connector Type |
N/A 10-32 Coaxial Jack at end of 3FT.cable |
Sensing Element Material |
N/A Planar Shear Piezoceramic |
Note for Mounting Provision |
N/A Flat mounting surface for adhesive mount. |
Weight (Less Cable) |
N/A 0.007 oz0.2 g |
Temperature Range |
N/A -60 to 350 ºF-51 to 177 ºC |
Maximum Peak Shock |
N/A 1000 g9800 m/s² |
Environmental Seal |
N/A Laser Welded, Epoxy Sealed Cable |
Base Strain Sensitivity at 250 Micro Epsilon (µe) |
N/A 0.0005 g/µε0.005 g/µε |
Maximum Root-Mean-Square (RMS) Vibration |
N/A 250 g2450 m/s² |
Sensitivity |
N/A 0.25 to 0.45 pC/g0.025 to 0.046 pC/m/s² |
Note for Sensitivity |
N/A
Measured at 100 Hz, 1 G rms per ISA RP 37.2. Actual sensitivity is given on a calibration certificate traceable to NIST, supplied with each instrument |
Frequency Response Tolerance |
N/A ±5 % |
Resonant Frequency |
N/A >40 kHz |
Maximum Transverse Sensitivity |
N/A 5 % |
Note for Frequency Response |
N/A Low frequency response is a function of the charge amplifier discharge time constant. |
Full Scale (F.S.) Amplitude Non Linearity (±) |
N/A 1 % |
Note for Amplitude Non Linearity |
N/A Measured using zero-based best straight-line method. |
Output Signal Polarity for Acceleration Toward Top |
N/A Negative |
Capacitance |
N/A 220 pF |
Minimum Insulation Resistance at Room Temperature |
N/A 5 x 108 O |
