Mounting Provision |
N/A 1/4 to 28 |
Maximum Weight |
N/A 4.73 oz135 g |
Material Body |
N/A 300 Series S.S. |
Connector Type (Side Exit) |
N/A 2 PIN |
Temperature Range |
N/A -40 TO +160 ºF-40 TO 71 ºC |
Thermal Coefficient of Sensitivity |
N/A 0.002 %/°F0.004 %/°C |
Maximum Peak Shock |
N/A 5000 g49000 m/s² |
Maximum Peak Vibration (±) |
N/A 500 g4900 m/s² |
Environmental Seal |
N/A Hermetic |
Full Scale (F.S.) Linearity (±) |
N/A ±1 % |
Maximum Transverse Sensitivity |
N/A 5% % |
Peak Full Scale (F.S.) Range for ± 5 Volts (V) Voltage Output (±) |
N/A ±50 g±490.5 m/s² |
Root-Mean-Square (RMS) Equivalent Electrical Noise Floor |
N/A 0.0005 g0.005 m/s² |
Frequency Range ±10% |
N/A 3.3 to 2500 Hz |
Strain Sensitivity @250µe |
N/A 0.001 g/µe0.01 m/s2/µe |
Frequency Range ±5% |
N/A 5 to 2000 Hz |
Sensitivity ±10% |
N/A 100 mV/g10 mV/m/s² |
Note for Sensitivity ±10% |
N/A Measured at 100Hz +/- Hz, 1 grms per ISA RP 37.2 |
Element Resonant Frequency |
N/A >15 kHz |
Root Mean Squire (rms) Spectral Noise rms/sqr(Hz) |
N/A 1 Hz: 800 10 Hz: 560 100 Hz: 360 1000 Hz: 200 10000 Hz: 80 µg1 Hz: 7848 10 Hz: 5439.6 100 Hz: 3531.6 1000 Hz: 1962 10000 Hz: 784.8 µm/s2 |
Power Supply Current |
N/A 2 to 20 mA |
Note for Power Supply Current |
N/A Do not apply power to this device without current limiting, 20 mA MAX. To do so will destroy the integral IC amplifier |
Compliance Voltage Range |
N/A +18 to +30 V |
Discharge Time Constant |
N/A 0.1 to 0.4 sec |
Typical Output Impedance |
N/A 100 O |
Direct Current (DC) Bias Voltage |
N/A 10 to 11.5 V |
Note for Electrical Isolation |
N/A Electrical ground isolated from sensor case |
