Maximum Weight (Less Cable) |
N/A 5 oz140 g |
Mounting Provision |
N/A 10-32 UNC-2B |
Connector from charge amplifier |
N/A 10-32 |
Housing Material, Accelerometer |
N/A Alloy 600 |
Housing Material, Charge Amplifier |
N/A Series S.S |
Maximum Peak Shock |
N/A 10000 g98100 m/s² |
Maximum Peak Vibration (±) |
N/A 6000 g58860 m/s² |
Maximum Peak Shock (±) |
N/A 10000 g98100 m/s² |
Seal (Accel. & Chg. amp) |
N/A Hermetic |
Resonant Frequency |
N/A >45 kHz |
Full Scale (F.S.) Linearity (±) |
N/A 1 % |
Note for Full Scale (F.S.) Linearity (±) |
N/A Measured using zero-based straight line method, % of F.S. or any lesser range. |
Maximum Transverse Sensitivity |
N/A 5 % |
Root-Mean-Square (RMS) Equivalent Electrical Noise Floor |
N/A 0.004 g0.04 m/s² |
Frequency Range ±10% |
N/A 5 to 3000 Hz |
Note for Linearity |
N/A Measured using zero-based straight line method, % of F.S. or any lesser range. |
Note for Sensitivity ±5% |
N/A Measured At 100 Hz, 1 Grms per ISA RP 37.2. |
Strain Sensitivity @250µe |
N/A 0.002 g/µe0.02 m/s2/µe |
Sensitivity ±10% |
N/A 10 mV/g1.0 mV/m/s² |
Linearity (±) |
N/A 1 % |
Temperature Range (Accelerometer) |
N/A -60 to 1000 F-51 to 538 ºC |
Temperature Range (Charge Amplifier) |
N/A -40 to 185 F-40 to 85 ºC |
Compliance Voltage Range |
N/A +18 to +30 V |
Direct Current (DC) Operating Bias Voltage |
N/A +10 to +13 V |
Discharge Time Constant |
N/A 0.1 to 0.5 sec |
Typical Output Impedance |
N/A 100 O |
Power Supply Current Range |
N/A 2 to 20 mA |
Note for Power Supply Current Range |
N/A Do not apply power to this device without current limiting, 20mA Max, to do so will destroy the integral IC amplifier. |
