Maximum Weight (Less Cable) |
N/A 0.07 oz2 g |
Mounting Provision |
N/A Adhesive |
Maximum Weight |
N/A 0.07 oz2 g |
Sensing Element Mode |
N/A Quartz |
Material |
N/A 300 Series Stainless Steel |
Electrical Connection |
N/A Integral Wires: Pigtails |
Sensing Material |
N/A Quartz |
Temperature Range |
N/A -60 to +392 ºF-51 to +200 ºC |
Maximum Peak Shock |
N/A 1500 g14715 m/s² |
Maximum Peak Vibration (±) |
N/A 1000 g9810 m/s² |
Environmental Seal |
N/A Epoxy |
Maximum Peak Shock (±) |
N/A 1500 g14715 m/s² |
Seal, Accelerometer |
N/A Seal: Epoxy |
Full Scale (F.S.) Range for ± 5 Volts (V) Voltage Output |
N/A ±500 g |
Resonant Frequency |
N/A >40 kHz |
Maximum Transverse Sensitivity |
N/A 5 % |
Frequency Response at ±3 Decibel (dB) Bandwidth |
N/A 25 to 10000 Hz |
Maximum Root-Mean-Square (RMS) Equivalent Electrical Noise Floor |
N/A 0.02 g0.196 m/s² |
Nominal Mounted Resonant Frequency |
N/A 25 to 10000 kHz |
Note for Linearity |
N/A Measured using zero-based best straight line method, % of F.S or any lesser range. |
Note for Sensitivity, ±30% |
N/A Measured at 1000Hz, 1 Grms per ISA RP 37.2 |
Sensitivity ±30% |
N/A 10 mV/g1 mV/m/s² |
Linearity (±) |
N/A ±2 % |
Compliance Voltage Range |
N/A +18 to +30 V |
Discharge Time Constant |
N/A 0.02 sec |
Nominal Output Impedance |
N/A 100 O |
Direct Current (DC) Operating Bias Voltage at Room Temperature |
N/A +7.5 to +9.5 V |
Direct Current (DC) Bias Voltage |
N/A At 200°C/392°F: +5.5 to +12.5 V |
Power Supply Current Range |
N/A 2 to 20 mA |
Note for Power Supply Current Range |
N/A Do not apply power to this system without current limiting, 20 mA MAX. To do so will destroy the IC charge amplifier. |
