Accelerometer Input Range (±) |
N/A 2 g19.6 m/s² |
Frequency Response |
N/A 0 to 200 Hz |
Frequency Response at ±3 Decibel (dB) Bandwidth |
N/A 0 to 400 Hz |
Frequency Response Tolerance |
N/A ±5 % |
Resonant Frequency |
N/A > 3,000 Hz |
Sensitivity Differential |
N/A 250 mV/g25 mV/m/s² |
Sensitivity Differential Tolerance (±) |
N/A 5 % |
Note for Sensitivity Differential |
N/A Single ended sensitivity is half of values shown. (Ref. at 100 Hz) |
Typical Root-Mean-Square (RMS) Differential Output Noise |
N/A 7 µg rms/√ Hz69 µm/s² rms/√ Hz |
Maximum Full Scale (F.S.) Non-Linearity (±) |
N/A 0.5 % |
Note for Maximum Full Scale (F.S.) Non-Linearity (±) |
N/A -90% to +90% of Full Scale |
Maximum Accelerometer Cross Axis Sensitivity |
N/A 3 % |
Maximum Weight (Less Cable) |
N/A 1.6 oz45 g |
Integral Cable |
N/A Flying Leads |
Material |
N/A Titanium Alloy |
Sensing Technology |
N/A Microelectromechanical System (MEMS) |
Maximum Peak Mechanical Shock (0.1 ms) |
N/A ±2,000 g±19,620 m/s² |
Maximum Bias Temperature Shift of Span |
N/A 111 ppm/ºF200 ppm/ºC |
Note for Maximum Bias Temperature Shift of Span |
N/A Over the rated temperature range. |
Maximum Bias Calibration Error of span |
N/A 4 % |
Operating Temperature Range |
N/A -67 to +257 ºF-55 to +125 ºC |
Environmental Seal |
N/A Hermetic |
Typical Direct Current (DC) Typical Output Common Mode Voltage |
N/A 2.5 V |
Nominal Output Impedance |
N/A 1,225 O |
Direct Current (DC) Operating Voltage |
N/A ±3 to ±11 V |
Maximum Operating Direct Current (DC) (Each Axis) |
N/A 13 mA |
Power Supply Rejection Ratio |
N/A > 65 dB |
Supplied Accessories |
N/A
|
