Sensitivity |
N/A 6.5 mV/g0.7 mV/m/s² |
Sensitivity Tolerance (±) |
N/A 10 % |
Note for Sensitivity |
N/A Measured at 100 Hz, 5 Grms per ISA RP 37.2. |
Peak Acceleration Range (±) |
N/A 200 g1962 m/s² |
Frequency Response for 50 Hertz (Hz) Frequency and ±3 Decibel (dB) Bandwidth |
N/A 0 to 1,300 Hz |
Resonant Frequency |
N/A > 16.5 kHz |
Full Scale (F.S.) Linearity (±) |
N/A 0.51 % |
Note for Full Scale (F.S.) Linearity (±) |
N/A Linearity is % of specified full scale (or any less full-scale range), zero-based best fit straight line method. |
Maximum Transverse Sensitivity |
N/A 5 % |
Spectral Noise |
N/A 2,700 µg rms/√ Hz26,487 µm/s² rms/√ Hz |
Sensitivity Change Due to Temperature (±) |
N/A 0.011 %/°F0.02 %/°C |
Housing Material |
N/A Aluminum, Anodized |
Maximum Weight (Less Cable) |
N/A 0.21 oz6.0 g |
Mounting |
N/A 2 x M2 Screws |
Cable Type |
N/A 6-Conductor |
Cable Material |
N/A Santoprene |
Housing Isolation |
N/A Case Isolated |
Maximum Peak Shock |
N/A 10,000 g98,100 m/s² |
Maximum Peak Vibration (±) |
N/A 5,000 g49,050 m/s² |
Operating Temperature Range |
N/A -40 to +185 ºF-40 to +85 ºC |
Environmental Seal |
N/A Epoxy |
Power Supply Current |
N/A 350 µA |
Direct Current (DC) Supply Voltage |
N/A 4 to 28 V |
Typical Output Impedance |
N/A 100 O |
Direct Current (DC) Operating Bias Voltage |
N/A 1.4 to 1.6 V |
Direct Current (DC) Output Voltage Range (±) |
N/A 1.5 V |
Self-Test Output |
N/A -6.5 mV |
Turn-On Time |
N/A 1 ms |
