Scale Factor Temperature Coefficient |
N/A -11 to +122 ppm/ºF-20 to +220 ppm/ºC |
Note for Scale Factor Temperature Coefficient |
N/A Over the rated temperature range. |
Resonant Frequency |
N/A >1900 Hz |
Typical Root-Mean-Square (RMS) Differential Output Noise |
N/A 17 µg rms/√ Hz167 µm/s² rms/√ Hz |
Maximum Transverse Sensitivity |
N/A 3 % |
Input Range |
N/A ±5 gPk±49.03 m/s2Pk |
Maximum Non-Linearity Full Scale |
N/A 0.5 % |
Frequency Response (±5%) |
N/A 0-1025 Hz |
Frequency Response (±3dB) |
N/A 0-1900 Hz |
Sensitivity Differential ±10% |
N/A 800 mV/g81.6 mV/m/s² |
Note for Sensitivity Differential ±10% |
N/A Single ended sensitivity is half of values shown |
Maximum Weight |
N/A 0.7 oz20 g |
Connector Type |
N/A 4-Pin, 1/4-28 UNF-2A |
Material |
N/A Titanium Alloy |
Thru Hole Mounting Provision |
N/A 2 X Ø 0.127 in2 X Ø3.23 mm |
Maximum Peak Mechanical Shock |
N/A 6000 g58840 m/s² |
Operating Temperature Range |
N/A -67 to +257 ºF-55 to +125 ºC |
Environmental Seal |
N/A Hermetic |
Nominal Output Impedance |
N/A 1 O |
Direct Current (DC) Operating Voltage |
N/A +6 to +14 V |
Power Supply Rejection Ratio |
N/A >65 dB |
Bias Calibration Error |
N/A 0.017 gPk0.0017 m/s2Pk |
Direct Current Operating Current (AOP & AON open) |
N/A 3 to 6 mA |
Warm up Time |
N/A <0.5 sec |
Overload Recovery |
N/A <200 µs |
Output Common Mode Voltage |
N/A 2.45 to 2.65 VDC |
Ground Isolation |
N/A >30 MO |
